Specialist Fasteners for Sheet Metal
+44 (0) 1302 836010
+44 (0) 1302 831555
Northern Precision Ltd YouTube Channel
Broaching fasteners are permanently attached in non-ductile materials such as printed circuit board, polycarbonate, acrylic, glass epoxy and resin laminate components as well as ductile panels with a maximum hardness of 60HRB such as aluminium.   Broaching fasteners are available in nut, stud, standoff, flare-mounted standoff, quick release standoff and panel access assembly styles and help to reduce loose components, reducing the risk of loose hardware being lost or falling out and damaging internal components.   Featuring an axially knurled shank or collar, the serrations are designed to cut into the panel material as it is installed, resulting in an interference fit that offers good torque-to-turn and push-out resistance. Installation is simple, prepare the specified hole and using an appropriate punch and anvil, apply a parallel squeezing force to press the part into the hole. When installing in printed circuit board broaching fasteners are recommended for use in non-plated holes.
Self Clinching Fastener Installation.
Take a look at our range of fastener installation presses here.
Broaching Nuts for Printed Circuit Board Broaching Studs for Printed Circuit Board Broaching Standoffs for Printed Circuit Board Flare Mounted Broaching Standoffs for Printed Circuit Board Quick Release Broaching Standoffs for Printed Circuit Board Broaching Panel Fasteners for Printed Circuit Board Broaching Nuts installed in Printed Circuit Board
